Icom IC-7800 Instruction Manual page 180

14
CONTROL COMMAND
D Command table (continued)
Command Sub command
15 01
02
11
12
13
14
15
16
16 02
12
22
32
40
41
42
43
44
45
46
47
48
4C
4D
4E
4F
50
19 00
1A 00
01
02
03
04
050001
050002
050003
050004
050005
050006
050007
050008
050009
050010
Description
Read squelch condition
Read S-meter level
Read RF power meter
Read SWR meter
Read ALC meter
Read COMP meter
Read V meter
D
Read I meter
D
Preamp (0=OFF; 1=preamp 1;
2=preamp 2)
AGC selection (0=OFF; 1=Slow;
2=Mid; 3=Fast)
Noise blanker (0=OFF; 1=ON)
Audio peak filter (0=OFF;
1=320 Hz; 2=160 Hz; 3=80 Hz)
Noise reduction (0=OFF; 1=ON)
Auto notch (0=OFF; 1=ON)
Repeater tone (0=OFF; 1=ON)
Tone squelch (0=OFF; 1=ON)
Speech compressor
(0=OFF; 1=ON)
Monitor (0=OFF; 1=ON)
VOX function (0=OFF; 1=ON)
Break-in (0=OFF; 1=semi break-
in; 2=full break-in)
Manual notch (0=OFF; 1=ON)
VSC (0=OFF; 1=ON)
Manual AGC (0=OFF; 1=ON)
DIGI-SEL (0=OFF; 1=ON)
Twin peak filter (0=OFF; 1=ON)
Dial lock (0=OFF; 1=ON)
Read the transceiver ID
Send/read memory contents (see
p. 14-9 for details)
Send/read band stacking register
contents (see p. 14-9 for details)
Send/read memory keyer con-
tents (see p. 14-9 for details)
Send/read the selected filter width
(SSB, CW, PSK: 0=50 Hz to
40=3600 Hz; RTTY: 0=50 Hz to
31=2700 Hz; AM: 0=200 Hz to
49=10 kHz)
Send/read the selected AGC time
constant (0=OFF, 1=0.1/0.3 sec.
to 13=6.0/8.0 sec.)
Send/read SSB TX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read SSB TX Tone (Treble)
level (0=–5 to 10=+5)
Send/read SSB RX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read SSB RX Tone (Treble)
level (0=–5 to 10=+5)
Send/read AM TX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read AM TX Tone (Treble)
level (0=–5 to 10=+5)
Send/read AM RX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read AM RX Tone (Treble)
level (0=–5 to 10=+5)
Send/read FM TX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read FM TX Tone (Treble)
level (0=–5 to 10=+5)
Command Sub command
1A 050011
050012
050013
050014
050015
050016
050017
050018
050019
050020
050021
050022
050023
050024
050025
050026
050027
050028
050029
050030
050031
050032
050033
050034
14-4
Description
Send/read FM RX Tone (Bass)
level (0 =–5 to 10=+5)
Send/read FM RX Tone (Treble)
level (0=–5 to 10=+5)
Send/read SSB TX bandwidth for
wide (see p. 14-10 for details)
Send/read SSB TX bandwidth for
mid. (see p. 14-10 for details)
Send/read SSB TX bandwidth for
narrow (see p. 14-10 for details)
Send/read speech level (0=0% to
255=100%)
Send/read CW side tone gain
(0=min. to 255=max.)
Send/read CW side tone gain limit
(0=OFF, 1=ON)
Send/read beep gain (0=min. to
255=max.)
Send/read beep gain limit (0=OFF,
1=ON)
Send/read headphones output
ratio (0=0.60 to 255=1.40)
Send/read headphone output
selection (0=separated, 1=mixed)
Send/read AF/SQL signal output
to ACC-A (0=Main; 1=Sub)
Send/read AF/SQL signal output
to ACC-B (0=Main; 1=Sub)
Send/read AF output level to
ACC-A (0=0% to 255=100%)
Send/read AF output level to
ACC-B (0=0% to 255=100%)
Send/read S/P DIF output level
(0=0% to 255=100%)
Send/read MOD output level to
ACC-A (0=0% to 255=100%)
Send/read MOD output level to
ACC-B (0=0% to 255=100%)
Send/read S/P DIF MOD output
level (0=0% to 255=100%)
Send/read MOD input connector
during DATA OFF
(0=MIC; 1=ACC-A; 2=ACC-B;
3=MIC/ACC-A; 4=MIC/ACC-B;
5=ACC-A/ACC-B; 6=MIC/ACC-
A/ACC-B; 7=S/P DIF)
Send/read MOD input connector
during DATA1
(0=MIC; 1=ACC-A; 2=ACC-B;
3=MIC/ACC-A; 4=MIC/ACC-B;
5=ACC-A/ACC-B; 6=MIC/ACC-
A/ACC-B; 7=S/P DIF)
Send/read MOD input connector
during DATA2
(0=MIC; 1=ACC-A; 2=ACC-B;
3=MIC/ACC-A; 4=MIC/ACC-B;
5=ACC-A/ACC-B; 6=MIC/ACC-
A/ACC-B; 7=S/P DIF)
Send/read MOD input connector
during DATA3
(0=MIC; 1=ACC-A; 2=ACC-B;
3=MIC/ACC-A; 4=MIC/ACC-B;
5=ACC-A/ACC-B; 6=MIC/ACC-
A/ACC-B; 7=S/P DIF)
