SADDLE STITCH FINISHER
Using the saddle stitch finisher functions
I Using the stapling function or saddle stitch function from the printer feature
When using the stapling function, select "Properties"
on the printer driver setting screen, open the "Main"
tab shown in the right illustration, and then select
"Left", "Right" or "Top" at Binding Edge and "1 Staple"
or "2 Staples" at "Staple".
When using the saddle stitch function, check the
radio button of "Pamphlet Style" at Document Style
and select "2 Staples" at "Staple" of "Finishing".
I Using the punch function with a punch
module installed as a peripheral unit
Open the "Main" tab and check "Punch" at
"Finishing".
NOTES
G For the settings above, installation of peripheral units must have been set properly in the properties of the printer driver (see
NOTE on page 2-5).
G Depending on the combination of paper selection and functions, the desired setting may not be possible. For details of
setting items, see the printer driver help. The details of the functions are described.
I Using the finisher functions in the copy mode
If you touch the [OUTPUT] key on the copy mode basic screen, a screen for selecting the sort/group/staple
functions and selecting an exit tray will appear.
[GROUP] key (See page xx.)
If this function is selected, all copies of the same
original will be grouped.
[STAPLE SORT] key (See page xx.)
If this function is selected, sorted copies will be
stapled and delivered to the offset tray. (not offset
stacked)
[SORT] key (See page xx.)
If this function is selected, each set of copies will be
sequentially delivered.
5-20
OUTPUT
OFFSET
SORT
TRAY
STAPLE
SORT
GROUP
OFFSET
The illustration below shows the screen for a PCL printer
driver in the Windows 98 environment.
OK
CENTER
TRAY
PUNCH
Icon display
The icon of the selected function (sort, staple sort,
group, saddle stitch or punch(only if the punch
module is installed)) is displayed.
[OFFSET TRAY] key (See page xx.)
If the offset tray is selected, printed sheets will be
delivered to the offset tray. (If the staple sort function
is selected, the offset tray will be automatically
selected.)
[CENTER TRAY] key
If the center tray is selected, printed paper will be
delivered to the exit tray located at the upper part of
the main unit.
