3. Press 0 twice to exit.
4. Disconnect the serial communication cable from the settings/sensor connector
To use the web interface to configure other network management card settings, see
Chapter 3, "Using the network management card web interface," on page 19.
Configuring the network settings without a DHCPv4 or DHCPv6 server
If your network is not connected to a DHCPv4 or DHCPv6 server, you must
configure the network management card manually. To set the network configuration,
complete the following steps:
1. From the main menu, press 2 (Network configuration). The following menu is
2. Press 2 (Modify Network settings).
3. Follow the instructions that are displayed on the screen and enter the static IP
4. Press 0 to exit.
5. Press 1 to reset the network management card.
6. Press 2 to restart the network management card with the new IP parameters.
7. Disconnect the serial communication cable from the settings/sensor connector
14
Network Management Card : User's Guide
Note: The IPv6 parameters are read-only.
and the computer.
displayed.
Note: You cannot configure the IPv6 address through the serial connection.
The IPv6 address is provided by the network management card or by the
IPv6 DHCP server (if an IPv6 DHCP server is available on the network).
To enable the IPv6 feature and configure IPv6 settings, see "Network
settings" on page 38.
-----------------------------------------------------------------------------
Network settings
-----------------------------------------------------------------------------
1 : Read Network settings
2 : Modify Network settings
3 : Set Ethernet speed
0 : Exit
-----------------------------------------------------------------------------
parameters. After you are finished entering the parameters, wait until the
message Done is displayed, indicating that the IP parameters are saved.
-----------------------------------------------------------------------------
Network settings
-----------------------------------------------------------------------------
1 : Read Network settings
2 : Modify Network settings
3 : Set Ethernet speed
0 : Exit
-----------------------------------------------------------------------------
For each of the following questions, you can press <Return> to select the
value shown in braces, or you can enter a new value.
Should this target obtain IP settings from the network?[N] N
Static IP address [166.99.21.94]? 166.99.21.21
Static IP address is 166.99.21.21
Subnet Mask IP address [255.255.248.0]? 255.255.255.0
Subnet Mask IP address is 255.255.255.0
Gateway address IP address [166.99.17.1]? 166.99.17.1
Gateway address IP address is 166.99.17.1
Wait until your new configuration is saved ...
Reset the card to take into account the new configuration.
and the computer.
