IBM Network Management Card User Manual page 34

24
Network Management Card : User's Guide
Table 15. DC to ac converter output
Icon
Table 16. AC bypass input
Icon
Table 17. AC automatic bypass flow
Icon
Table 18. AC automatic bypass status
Icon
Table 19. AC manual bypass flow
Icon
Color
Yellow
Gray
Color
Green
Red
Color
Yellow
Gray
Color
Green
Gray
Red
Color
Yellow
Gray
Description
Energy flow present
No energy flow
Description
In tolerance
Out of tolerance
Description
Energy flow present
No energy flow
Description
Powered
Not powered
Internal failure
Description
Energy flow present
No energy flow
