Front Panel Operations
The following sections detail the power‑up process and then provide sample procedures for
the following actions:
•
•
•
•
•
•
•
•
•
•
•
Definitions
The following terms apply to Extron Matrix Switchers, and are used throughout this guide:
Tie — An input‑to‑output connection.
Set of ties — An input tied to two or more outputs. (An output can never be tied to more
than one input.)
Configuration — May consist of one tie or one or more sets of ties.
Current configuration — The configuration that is currently being used (also called
configuration 0).
Global memory preset — A configuration that has been stored. The FOX Matrix 3200
can store up to 32 global memory presets in memory and the FOX Matrix 7200 can store
up to 64 presets. When a global preset is retrieved from memory, it becomes the current
configuration.
Room — A Room consists of a smaller subset of virtual outputs that are logically related to
each other, as determined by the operator. The switchers support up to 32 rooms, each of
which consists of 1 to 16 virtual outputs.
Room memory preset — A configuration consisting of virtual outputs in a single room
that has been stored. When a room preset is retrieved from memory, it becomes the current
configuration. The switchers support up to 10 room presets per room. Selecting a room
preset only changes the ties to outputs that are assigned to that room. All other ties outside
the room are not affected.
Creating ties, sets of ties, and configurations
Changing a configuration
Viewing ties, sets of ties, and configurations
Creating I/O groups
Saving a preset
Recalling a preset
Muting and unmuting outputs
Locking and unlocking the front panel
Performing front panel resets
Toggling background illumination on and off
Reading and setting the Remote RS-232/RS-422 port settings
FOX Matrix 3200 and 7200 Switchers • Operation
25
