5. Connect the computer to either
port (see page 13) of the switcher.
6.
Start the Matrix Switchers Control Program and connect to the matrix switcher (see
Using the Matrix Switcher Control Software
starting on page 73).
7. Click >
Tools Update firmware
• If the switcher is connected via the LAN port, the select file window appears
(see figure 39). Perform "Ethernet‑connected firmware upload," below.
Figure 39. Select File Window
If the switcher is connected via either serial port, the Extron Firmware Loader
•
window opens (see
on the next page).
Ethernet-connected firmware upload
1. Navigate to the folder where you saved the firmware upgrade file (see figure 39, above).
Select the file.
2. Click the button. The software advises you that you are about to reprogram the
Open
switcher firmware. Click
A status window, which shows the progress of the
upload, appears. The firmware upload to the FOX
matrix switcher may take a few minutes.
(see page 13 and page 17) or the
serial port
... .
figure 40 and Serial-port-connected firmware upload
to continue.
OK
FOX Matrix 3200 and 7200 Switchers • Matrix Software
in this chapter, steps 1 through 3,
1
LAN
