Opening the Embedded Web Pages

Access the switcher using HTML pages as follows:
1.
2.
3.
4.
5.
6.
Start the web browser program.
Click in the field of the browser.
Address
Enter the Matrix IP address in the
NOTE: If the local system administrators have not changed the value, the factory‑
specified default, 192.168.254.254, is the correct value for this field.
If you want the browser to display a page other than the default page (such as a custom
page that you have uploaded), enter a slash (
NOTES:
• The field of the browser should display the address in the following
Address
format: <
xxx.xxx.xxx.xxx
• The HTML language reserves certain characters for specific functions (see
Special Characters
Press the keyboard <Enter> key. The switcher checks to see if it is password protected.
If the switcher is not password protected, it checks and downloads the HTML pages
(proceed to step 7).
If the switcher is password protected, the switcher downloads the Windows Security
dialog box (see figure 52).
Figure 52. Windows Security Dialog Box
NOTE: A User name entry is not required.
Click in the field and type in the appropriate administrator or user password.
Password
Click the button.
OK
FOX Matrix 3200 and 7200 Switchers • HTML Operation
field of the browser.
Address
) and the file name to open.
/
>/<
optional_file_name
on page 70).
>.html.
94
