Installing and Removing Memory Modules

007-4278-001
The three 168-pin sockets onboard support SDRAM-type DIMMs. You may install
64-MB, 128-MB, 256-MB, or 512-MB (single and double density) DIMMs for a maximum
of 1.5 GB of system memory.
Note: The SDRAM works at 3.3 volts only; 5-volt memory devices are not supported.
This system board supports 100-MHz and 133-MHz SDRAM. However, they cannot be
used at the same time in the system.
Warning:
Do not use both 100-MHz and 133-MHz SDRAM together. This might
cause your system to malfunction. For a qualified DIMM vendor list, please contact
your reseller.
Each of the DIMM sockets is independent from the others. This independence allows you
to install DIMMs with different capacities to form different configurations.
To install a DIMM, align it to an empty slot and press it in until the holding clips secure
the DIMM in place, as show in Figure 3-4.
Figure 3-4 Installing a DIMM
System Component Installation
65
