4: Setup Utility

IDE Channel Type

80
Table 4-3 Disk Drives Screen Parameters
Parameter Description
Diskette drive Selects the floppy disk drive type
A and B
IDE primary These items let you select the IDE
channel hard disk parameters that your
master and system supports. Auto enables BIOS
slave to automatically detect the
parameters of installed HDDs during
IDE
the POST (power-on self-test). If you
Secondary
prefer to enter HDD parameters
channel
manually, select User. Select None if
master and
no HDD is connected to the system.
slave
The IDE CD-ROM is always
automatically detected
The screen in Figure 4-6 appears if you select any of the IDE drive parameters.
Option
1.44 MB, 3.5-in.
None
360 KB, 5.25-in.
1.2 MB, 5.25-in.
720 KB, 3.5-in.
2.88 MB, 3.5-in.
Auto
User
None
007-4278-001
