7. Other Functions

[1] Pixel to Pixel
• LVM-070C monitor provide pixel count info •
using Pixel to Pixel mode.
1. Select [Scan] mode in the OSD menu to
activate the[Pixel To Pixel] mode.
2. After activation of [Pixel To Pixel] mode, use
the Knob to move the position.
Input Action
[Scroll UP]
(Clockwise)
HD 720p
/1080i
[Scroll DOWN]
/1080p
(Counter
clockwise)
# Pixel to Pixel mode is not available for Graphic
Signal input.
# Pixel to Pixel mode works for SD signal, when
the input resolution is lower than the monitors
native resolution.
• • Positions in HD Signal 1080i/1080p mode
UP
DOWN
<CENTER> <LEFT TOP>
UP
DOWN
<RIGHT BOTTOM>
Available Modes
Center -> Left Top -> Right Top -> Right
Bottom -> left Bottom -> Center -> ...
Center -> Left Bottom -> Right
Bottom -> Right Top -> Left Top ->
Center -> ....
UP
DOWN
<RIGHT TOP>
UP
DOWN
<LEFT BOTTOM>
Multi Format LCD Monitor 23
