V i p e r s a t C o n f i g u r a t io n

Force Modem to Home State

If at any time it is desired to have a CDD-56X return to its Home State, this
command (enter Y) can be executed. A warning message is displayed as shown
in figure 3-56, requiring the command to be confirmed before it is executed.
Figure 3-56
Force Modem to Home State warning
This command will force the selected Demod to its Home State configuration,
replacing its current configuration.

STDMA State

This command (enter T) toggles the setting of STDMA in the target
CDD-56X's Home State between Enabled and Disabled. This is the same
feature that is set from the Feature Configuration menu screen shown in
figure 3-4. Setting the STDMA State to Enabled is only applicable for a
CDD-56X that is configured as a Hub burst controller.
Note: Only one demod can be set with STDMA enabled. Vipersat recommends
NOTE
that Demod 1 be utilized for applications calling for STDMA.

Receive Frequency

Enter M to use the dialog shown in figure 3-57 to set the Receive Frequency
for the selected Demod's Home State.
Figure 3-57
Receive Frequency prompt
C h ap t e r U s i n g t h e C o m m a n d L in e I n t e r f a c e ( C L I )
3 - 3-45
