Lowering the Up-down Unit of the Spectrophotometer Unit (option) Manually
1
Open the Spectrophotometer Unit Cover.
2
Press down on the center (near the blue label) of the
Up-down Unit to lower the Up-down Unit.
Perform the target operation in this state.
3
Close the Spectrophotometer Unit Cover.
When pressing down on the Up-down Unit, handle the central part (near the blue label). Handling the ends may cause dam-
•
age.
Note
• After the paper operations are complete, the Up-down Unit will automatically return to its original position.
