Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option)
5
Grasp the part with the blue label in the central part of
the Spectrophotometer Carriage and move it to the po-
sition shown in the diagram.
6
Open the Spectrophotometer Sensor Cover.
7
Remove the Power Supply Connector and Mini USB
Connector from the Spectrophotometer Sensor.
930
iPF6400S
User's Guide
