iPF6400S
• If it is difficult to load rolls from the front of the printer, load rolls from the back of the printer.
If the printer has a Spectrophotometer Unit (option), lowering the Up-down Unit makes it easier to perform opera-
Note
tions from the front of the printer. (See "Lowering the Up-down Unit of the Spectrophotometer Unit (option) Manual-
ly.")
P.531
➔
5
Insert the edge of the roll in the Paper Feed Slot (a)
and advance the roll until you hear the feed tone.
• Be careful not to soil the printing surface of roll paper as you insert it in the slot. This may affect the printing quality.
We recommend wearing clean cloth gloves when handling rolls to protect the printing surface.
Important
• If the paper is wrinkled or warped, straighten it out before loading it.
Load paper straight so it is not fed askew.
•
6
Once paper feeding starts, you will need to do the following, based on the ManageRemainRoll setting and the
barcode printed on rolls. (See "Keeping Track of the Amount of Roll Paper Left.")
ManageRemainRoll
Off Printed
Not printed
On Printed
Not printed
• For details on types of paper to select, see the Paper Reference Guide. (See "Displaying the Paper Reference
Guide.")
Note
7
Close the Roll Feed Unit Cover.
• Cut the edge of the roll using the Paper Cutting function if the edge is creased or soiled. (See "Specifying the
Cutting Method for Rolls.")
Important
User's Guide
Barcodes
A menu for selection of the type of paper is shown on the Display Screen.
Press ▲ or ▼ to select the type of paper, and then press the OK button.
The type and amount of paper left is automatically detected based on the barcode printed on the roll.
There is no need to specify the type and length of the paper.
A menu for selection of the type and length of paper is shown on the Display Screen.
Press ▲ or ▼ to select the type and length of paper loaded, and then press the OK button.
P.500
➔
P.520
➔
Printer Operation After the Paper is Fed
Loading Rolls in the Printer
P.518
➔
