Canon imagePROGRAF iPF6400S User Manual page 945

iPF6400S
2
Remove the jammed paper from the Paper Feed Slot.
3
Attach the Roll Feed Unit to the printer. (See "Installing the Roll Feed Unit.")
Remove scraps left in the Paper Feed Slot
Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper.
1
Press the Load button.
2
Press ▲ or ▼ to select Manual Paper, and then press the OK button.
A menu for selection of the type of paper is displayed.
3
Select POP Board and press the OK button.
Instructions for feeding POP Board are now displayed on the Control Panel, but follow this procedure to re-
move the jammed paper.
4
Open the Top Cover.
5
Fold an A4 sheet lengthwise four times and insert it through
the gap of the Back Cover. Push the scrap out toward the
Platen.
6
Remove the scrap when it is pushed out onto the Platen.
7
If any scraps remain inside the paper feed slot, repeat steps 5 and 6.
8
Close the Top Cover.
9
Turn the printer off. (See "Turning the Printer On and Off.")
User's Guide
Clearing Jammed Paper (Paper Feed Slot)
P.530
➔
P.21
➔
945
