iPF6400S
5
Refer to the following table to confirm the number on the Platen
(a) that corresponds to the size of paper for printing.
Number
2 254 mm (10 in) or 257 mm
3 355 mm (14 in)
4 406 mm (16 in), 420 mm, or 432 mm (17 in)
5 515 mm (20 in)
6 610 mm (24 in)
6
Using the back of the Cleaning Brush, move the Switch to the side opposite ●, corresponding to the size of the
paper for printing.
In this case, note that you will move the switch in the opposite direction from the direction in step 4.
The Switch only moves number 1 and the number that matches
•
the paper size. Set all of the switches where the number does not
Note
match the paper size in switches number 2 and higher to the ●
side.
7
Close the Top Cover.
User's Guide
Dimensions
10"x12", 8"x10", or JIS B4
14"x17"
16-in. Roll (406.4mm), ISO A2, 17-in. Roll (431.8mm), or ANSI C
JIS B2 or JIS B3
ISO A1, ISO A2, or 20"x24"
Setting the Blue Switch on the Platen
Paper Size
