To do...
Configure the port to operate in
automatic voice VLAN
assignment mode
Enable voice VLAN on the port
An switch 4510G supports up to eight voice VLANs globally.
A protocol-based VLAN on a hybrid port can process only untagged inbound packets, whereas the
voice VLAN in automatic mode on a hybrid port can process only tagged voice traffic. Therefore,
do not configure a VLAN as both a protocol-based VLAN and a voice VLAN. For more information,
refer to Protocol-Based VLAN
Do not configure the default VLAN of a port in automatic voice VLAN assignment mode as the
voice VLAN.

Setting a Port to Operate in Manual Voice VLAN Assignment Mode

Follow these steps to set a port to operate in manual voice VLAN assignment mode:
To do...
Enter system view
Enable the voice VLAN
security mode
Add a recognizable OUI
address
Enter interface view
Configure the port to operate in
manual voice VLAN
assignment mode
Assign the
port in manual
voice VLAN
assignment
mode to the
voice VLAN
Use the command...
voice vlan mode auto
voice vlan vlan-id enable
Configuration.
Use the command...
system-view
voice vlan security enable
voice vlan mac-address oui
mask oui-mask [ description
text ]
interface interface-type
interface-number
undo voice vlan mode auto
Refer to
Access port
Port to a
Refer to
Trunk port
to a VLAN.
Refer to
Hybrid port
Port to a
Assigning an Access
VLAN.
Assigning a Trunk Port
Assigning a Hybrid
VLAN.
8-5
Remarks
Optional
Automatic voice VLAN
assignment mode is enabled
by default.
The voice VLAN assignment
modes on different ports are
independent of one another.
Required
Not enabled by default
Remarks
—
Optional
Enabled by default.
Optional
By default, each voice VLAN
has default OUI addresses
configured. Refer to Table 8-1
for the default OUI addresses
of different vendors.
—
Required
Disabled by default
Use one of the three
approaches.
After you assign an access port
to the voice VLAN, the voice
VLAN becomes the default
VLAN of the port automatically.
