Output Channels

There are six output channels available for routing audio to the external
system. The output channels are labelled 1-6 on the front of the unit. To select
any one of the 6 output bands, either press the rotary encoder until the output
is shown on the screen, or press the relevant assign key in the outputs area on
the front panel. The assign button illuminates to show the output is selected.
The outputs can be sourced from any of the input channels and in various
combinations dependant on the configuration set in the Utilities and source
settings made for each output channel.
The edit screens associated with the outputs are in the order as follows:
1. Name
2. Source
3. Low crossover - shape and frequency
4. High crossover - shape and frequency
5. Phase & Polarity
6. Gain
7. Limiter
8. Delay Link
9. Delay
10. EQ Bypass
11. DEQ (Dynamics parameters)
12. DEQ (EQ settings)
13. EQ 1
Further EQs can then be assigned if required/available.
The facilities described in this section are common to all outputs.
