Summary of Contents for BSS Audio Soundweb London BLU-102
- Page 1 Soundweb London BLU-102 Installation Guide 18-0771-B...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING FOR YOUR PROTECTION READ THE FOLLOWING: KEEP THESE INSTRUCTIONS HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS THE APPARATUS SHALL NOT bE ExPOSED TO DRIPPING OR SPLASHING The symbols shown above are internationally accepted symbols LIqUID AND NO ObjECT FILLED WITH LIqUID, SUCH AS vASES, SHALL that warn of potential hazards with electrical products. -
Page 3: Declaration Of Conformity
IMPORTANT SAFETY INSTRUCTIONS DECLARATION OF CONFORMITY U.K. MAINS PLUG WARNING Manufacturer’s Name: BSS Audio A molded mains plug that has been cut off from the cord is unsafe. Discard Manufacturer’s Address: 8760 S. Sandy Parkway the mains plug at a suitable disposal facility. NEVER UNDER ANY... -
Page 4: Regulatory Information
This equipment must be earthed. It should not be necessary to remove any protective earth or signal cable shield connections to prevent ground loops. Any such disconnections are outside the recommended practice of BSS Audio, and will render the EMC or safety certificate void. -
Page 5: Front Panel
Front panel Input/Output channel monitoring Each channel has the following LED indicators: Clip Indicates clipping in the analogue domain for each input or output channel. The LED will illuminate at +18.5dB. Signal The Signal LED will illuminate for each input or output channel when the signal reaches or exceeds the signal threshold of -20dB. - Page 6 Audio cable wiring All audio and GPIO connections to the BLU-102 are via Klippon pluggable terminal block connectors (also known as BL, Phoenix or Combicon). The BLU-102 includes 3-way female Klippon connectors for individual channels. Audio Input and Output wiring convention Soundweb products provide cable shielding ‘back from the destination’...
-
Page 7: Rear Panel
The London BLU link is a point-to-point digital audio bus with 256 audio channels at 48K sample rate or 128 audio channels at 96K sample rate. The BLU-102 allows access to channels 1-48 of this bus, at 48K sample rates. The physical connection is made with Cat 5e cable from the OUT port of one device to the IN port of another device. - Page 8 Non-Linear Processing (NLP) dynamically adjusts to minimize echo caused by under or over-cancellation. Telephone Jack The BLU-102 has a telephone hybrid in and out channel via a telephone jack. This RJ-11 jack allows connection to a standard POTS (aka PSTN or Analog PBX) telephone network. CONTROL INPUTS Used to connect switches or potentiometers, e.g.
- Page 9 OPTO Output In addition to the six standard LOGIC OUTPUTS, there is an isolated output, which fails safe (open circuit) if the unit becomes faulty. 47kOhm 10K-100kOhm linear unconnected lad- lad- switch switch 2 wire mode 3 wire mode +supply relay relay ground...
-
Page 10: Technical Specifications
Technical specifications FRONT PANEL LED INDICATORS Signal Clip, Signal Present, 48V (input only), Off Hook (OH) Other: Control link status and activity for Ethernet and RS-232 connections (COM); Device configuration status (STAT); Error (ERR); Power/Locate (PWR) ANALOGUE INPUTS: 10 electronically balanced on Phoenix/Combicon removable screw connectors Mic/Line Inputs: Nominal gain 0dB, electronically switchable up to +48dB,... - Page 11 Please contact BSS Technical Support for more information on purchasing replacement parts or product service. BSS Audio has a policy of continued product improvement and accordingly reserves the right to change features and specifications without prior notice.
- Page 12 If this equipment BLU-102 causes harm to the telephone network, the telephone company will notify you in advance that tempo- rary discontinuance of service may be required. But if advance notice isn’t practical, the telephone company will notify the cus- tomer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. f) The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the operation of the equipment. If this happens the telephone company will provide advance notice in order for you to make necessary modifica-...
