Quick Start Guide

Getting going with
a preconfigured
program
• Program recall
If the FDS-366T has already been configured with a suitable program, you
only need to use the recall mode to set the parameters to that program.
! Be aware that different programs may contain inappropriate routings
T
and EQ/Limiter settings for your particular system so care should be
exercised when selecting the correct program.
Press RECALL. Turn the rotary encoder to select the required program by
number and name, and press RECALL again.
Programs marked with diamonds are 'OEM' programs and have usually been
designed to match specific sound systems. Programs marked with a padlock
symbol are 'Owner' programs. Either of these two types of locked programs
may only allow edting access of some of the units functions.
Some units will be locked to a specific program only, in this case most controls
will be disabled and the unit will be ready for use.
• Recalling a program from a PC Card
To load programs from a PC card:
1 Push the card into the slot on the front panel of the FDS-366T.
2 Press RECALL.
Press 'v' on the navipad control to highlight "Int", and turn the encoder
3
to select "6Prg" (or "6All" for a full PC Card recall).
4 Press the '^' key to return to file selection, and turn the rotary encoder to
select the required program.
5 Push RECALL again to recall the program as the current setting.
5Prg and 5All are for the recall of FDS-355 programs which can be read by the
FDS-366T (refer to the PC Card chapter for more info).
Getting some output:
Having selected the appropriate program for the application of the Omnidrive
now it is time to apply some audio source material to the unit's inputs. By
default all the output mutes should be lit red, i.e. channels muted, so to hear
the signal unmute the outputs one by one checking that the sound output is
correct for the speaker system required. Adjust the trim levels as necessary to
acquire the correct volume balance.
A brief explanation of how to edit the Omnidrive's parameters follows on the
next page.
