Quick Start Guide
Use the navipad ^/v keys to select the delay screen. The delay is adjusted
using the rotary encoder.
Default settings for display and adjustment of delay is in meters (m), but can
be changed to milliseconds (ms), feet/inches (ft) or frames per second (fps)
using the "Delay Units" parameter in the Utilities.
Bands can also be linked so multiple outputs can be delayed as one using the
"Delay Link" facility.
•
Adding EQ
Use the navipad ^/v keys to move to the EQ screen. The EQ shape can be
edited first. The shape of the EQ can be selected from one of the following by
turning the rotary encoder:
High Shelf with 12dB slope (Hi12)
High Shelf with 6dB slope (Hi6)
Bell
Low Shelf with 6dB slope (Lo6)
Low Shelf with 12dB slope (Lo12)
Navigate around the other EQ parameters using the navipad to adjust:
-
Filter Frequency (kHz)
-
Cut/Boost (dB)
-
Filter Bandwidth (Oct) (bell EQ only)
Once an EQ has been set, press ^ again to assign a new EQ (if required).
•
Setting the limiters
There are several parameters associated with the limiters of the FDS-366T,
which allow you to:
-
Switch the limiter (On/Off)
-
Adjust the limiter threshold (Thr)
-
Adjust the attack & release times (Atk & Rel)
-
Adjust the brickwall limiter overshoot (Over)
The output meters are calibrated to the threshold, so the threshold value will
determine the reference of '0' on the meter at all times, even if the limiters
are off. The threshold is indicated in dBu, but can be changed to mV via the
Limiter Units screen in the Utilities.
•
Storing your settings
- 43 -
FDS-366T
