Searching

You can use // to search for elements anywhere in the status or
configuration hierarchy (Example 1).
You can also combine multiple //'s (Example 2).
WARNING: The search shortcuts work well for inspecting the API, but
should not be used in applications. We recommend that you always
use the complete paths to avoid command ambiguity when upgrading
to newer firmware releases.

Value types and formats

The system supports the following value types (Example 3):
• Integer values: <x..y>
Defines the valid range for an integer input. x = min value,
y = max value.
• Literal values: <X/Y/../Z>
Defines the possible values for a given configuration.
• String values: <S: x, y>
Defines that the valid input for this configuration is a string with
minimum length of x and maximum length of y characters. Strings
can have rules that further specify their format and length.
Input values that contain spaces need to be quoted
Any values for configurations and commands containing spaces must
be enclosed in quotes. Quotes are not necessary for values without
spaces.
Examples:
Correct: xCommand dial number: "my number contains spaces"
Correct: xCommand dial number: 12345
xCommand dial number: my number contains spaces
Incorrect:
Case sensitivity
All commands are case-insensitive. All of the following commands will
work.
XCOMMAND DIAL NUMBER: foo@bar.org
xcommand dial number: foo@bar.org
xCommand Dial Number: foo@bar.org
D14642.15 Codec C40-C60 API Reference Guide TC7.0, JANUARY 2014.
About the API About the API xConfiguration
Example 1: List all configurations that include a word that starts with DVI:
xConfiguration //dvi
*c xConfiguration Video Input DVI 2 RGBQuantizationRange: Full
*c xConfiguration Video Input DVI 2 Type: AutoDetect
*c xConfiguration Video Input DVI 3 RGBQuantizationRange: Full
*c xConfiguration Video Input DVI 3 Type: AutoDetect
*c xConfiguration Video Output DVI 2 RGBQuantizationRange: Full
*c xConfiguration Video Output DVI 2 Resolution: 1024 _ 768 _ 60
*c xConfiguration Video Output DVI 2 OverscanLevel: None
*c xConfiguration Video Output DVI 2 MonitorRole: Second
** end
Example 2: Get the resolution width of all connected sources for both inputs and outputs:
xStatus //vid//res//wid
*s Video Input Source 1 Resolution Width: 1920
*s Video Input Source 2 Resolution Width: 0
*s Video Input Source 3 Resolution Width: 0
*s Video Output HDMI 1 Resolution Width: 1920
*s Video Output DVI 2 Resolution Width: 1024
*s Video Output Legacy 3 Resolution Width: 720
** end
Example 3: Value types and formats
xConfiguration ??
*? xConfiguration Audio Microphones Mute Enabled: <True/InCallOnly>
*? xConfiguration Audio Volume: <0..100>
*? xConfiguration Audio SoundsAndAlerts RingVolume: <0..100>
.
.
.
*? xConfiguration Video Output Composite[3] Resolution: <PAL/NTSC>
*? xConfiguration Video Output Composite[3] OverscanLevel: <Medium/High/None>
*? xConfiguration Video Output Composite[3] MonitorRole: <Auto/First/Second/PresentationOnly/
Recorder>
** end
