Cisco TelePresence System Codec C40 Reference Manual page 172

Cisco TelePresence System Codec C40/C60
Contents Introduction
xStatus ICE Call Remote IP
Returns the IP address the remote system is using for media routing in the present call.
Value space of the result returned:
<String>
Example:
xStatus ICE Call Remote IP
*s ICE Call 1 Remote IP: "192.0.1.20"
** end
xStatus ICE Turn Discovermode
Returns the result of the turn server test, if xConfiguration SIP Profile[1] Turn DiscoverMode is set to
On.
Verified: The server was reached, and the user name and password were received.
NotVerified: Configuration has been received, but neither server or credentials has been verified.
Failed: The server was not reached.
Off: Turn discovery mode is set to Off.
Value space of the result returned:
<Verified/NotVerified/Failed/Off>
Example:
xStatus ICE Turn Discovermode
*s ICE Turn Discovermode: "Verified"
** end
D14642.15 Codec C40-C60 API Reference Guide TC7.0, JANUARY 2014.
About the API xConfiguration
xStatus ICE Turn Bandwidth
172
xCommand
Returns the bandwidth available for the turn server right after xConfiguration SIP Profile 1 Turn
BandwidthProbe is set to On.
Probing failed: Could not obtain information on bandwidth.
Probe Aborted: The probing was canceled because a call started.
Probe Connected: The probing has stared.
Probe progress: Shows the bandwidth at this stage of the test.
Probe stopped with loss: The probing finished, because packet loss was detected. The loss is
shown in kbps.
Probe Completed: The probing completed. The bandwidth result shown in kbps.
Value space of the result returned:
<"Probing failed"/"Probe Aborted"/"Probe Connected"/"Probe progress"/"Probe stopped with
loss: kbps"/"Probe Completed: kbps">
Example:
xStatus ICE Turn Bandwidth
*s ICE Turn Bandwidth: "Probe Completed: 6000kbps"
** end
API Reference Guide
xStatus xStatus Appendices
