xStatus Video Output DVI [n] MonitorRole
Describes which video stream is shown on the monitor connected to the video output DVI
connector.
First/Second/Third/Fourth: The role of the monitor in a multi-monitor setup. In a singlemonitor setup,
there is no difference between First, Second, Third and Fourth.
PresentationOnly: Shows presentation video stream if active.
Recorder: Shows all participants, including the local main video. If active, shows also the
presentation.
InternalSetup: Determined by the system, when xConfiguration Video Output HDMI [n] MonitorRole
is set to Auto.
Value space of the result returned:
<First/ Second/ Third/ Fourth/ PresentationOnly/ Recorder/ InternalSetup>
Example:
xStatus Video Output DVI 2 MonitorRole
*s Video Output DVI 2 MonitorRole: First
** end
xStatus Video Output DVI [2] Resolution Height
Shows the resolution height (in pixels) for the video output DVI.
Value space of the result returned:
<120..3000>
Example:
xStatus Video Output DVI 2 Resolution Height
*s Video Output DVI 2 Resolution Height: 720
** end
xStatus Video Output DVI [2] Resolution Width
Shows the resolution width (in pixels) for the video output DVI.
Value space of the result returned:
<176..4000>
Example:
xStatus Video Output DVI 2 Resolution Width
*s Video Output DVI 2 Resolution Width: 1280
** end
D14642.15 Codec C40-C60 API Reference Guide TC7.0, JANUARY 2014.
About the API xConfiguration
xStatus Video Output DVI [2] Resolution RefreshRate
xStatus Video Output DVI [2] Connected
210
xCommand
Shows the resolution refresh rate (Hz) for the video output DVI.
Value space of the result returned:
<1..300>
Example:
xStatus Video Output DVI 2 Resolution RefreshRate
*s Video Output DVI 2 Resolution RefreshRate: 60
** end
Indicates whether a display is connected to the DVI video output or not. NOTE: When a display
enters standby mode, the endpoint may not be able to detect it. The connector status will then
return False/Unknown even if the display is physically connected.
True - A display is connected to the video output connector
False - No display is connected to the video output. Applicable to digital outputs only.
Unknown - Because both digital and analog are supported on the DVI-I connector, in some
situations it is uncertain whether a display is connected or not. Therefore, the state is Unknown by
default. However, when EDID is received from a display the state will be True.
Value space of the result returned:
<True/False/Unknown>
Example:
xStatus Video Output DVI Connected
*s Video Output DVI 2 Connected: Unknown
** end
