Dial commands
xCommand Dial
Dial out from the system. Returns information about the CallId and ConferenceId, which are required
for some other commands.
Number: Enter the number or address.
Protocol: Select the SIP, H323 or H320 protocol.
CallRate: Set a call rate.
CallType: Select the audio or video call type.
BookingId: Any identifier that an external booking system (e.g. TMS, CTS-MAN) can use for its own
references to match placed calls with the booking systems internal identifier for a meeting. This can
be any string, e.g. a GUID. The booking Id is supplied in call logs, call events etc for the call.
DisplayName: The display name of the remote participant.
Requires user role: USER
Parameters:
Number(r): <S: 0, 255>
Protocol: <H320/H323/Sip>
CallRate: <64..6000>
CallType: <Audio/Video>
BookingId: <S: 0, 255>
Appearance(o): <1..999999999>
DisplayName(o): <S: 0, 255>
Example:
xCommand Dial Number:543210 Protocol:h323
OK
*r DialResult (status=OK):
CallId: 2
ConferenceId: 1
** end
D14642.15 Codec C40-C60 API Reference Guide TC7.0, JANUARY 2014.
About the API xConfiguration
DTMFSend commands
xCommand DTMFSend
109
xCommand xCommand
Send DTMF tones to the far end.
CallId: The CallID is returned when the xCommand Dial command is run. During the call you can run
the xStatus Call command to see the CallId.
DTMFString: Enter the DTMF string.
Requires user role: USER
Parameters:
CallId: <0..65534>
DTMFString(r): <S: 0, 32>
Example:
xCommand DTMFSend CallId:2 DTMFString:1234
*r DTMFSendResult (status=OK):
** end
