5-6 Troubleshooting
Viewing and Clearing
Events
20-COMM-M Modbus/TCP Adapter User Manual
Publication 20COMM-UM014C-EN-P
The adapter has an event queue to record significant events that occur in the
operation of the adapter. When such an event occurs, an entry is put into the
event queue. You can view the event queue using an LCD PowerFlex
7-Class HIM, DriveExplorer (2.01 or higher) software, DriveExecutive
(1.01 or higher) software or other clients using the DPI Fault object.
The event queue can contain up to 32 entries. Eventually the event queue
will become full, since its contents are retained through adapter resets. At
that point, a new entry replaces the oldest entry. Only an event queue clear
operation or adapter power cycle will clear the event queue contents.
Resetting the adapter to defaults has no effect on the event queue.
Using the HIM to View and Clear Events
Step
Viewing Events
1. Access parameters in the adapter. Refer to
7-Class HIM on page 3-2.
2. Press the or key to scroll to Diagnostics.
3. Press the (Enter) key to display the Diagnostics menu in the
adapter.
4. Repeat steps 2 and 3 to enter the Events option and then View
Event Queue option.
5. Press the or key to scroll through events. The most
recent event is Event 1.
Clearing Events
1. Access parameters in the adapter. Refer to
7-Class HIM on page 3-2.
2. Press the or key to scroll to Diagnostics.
3. Press the (Enter) key to display the Diagnostics menu in the
adapter.
4. Repeat steps 2 and 3 to enter the Events option and then the Clear
Event option or Clr Event Queue option. A message will pop up to
confirm that you want to clear the message or queue.
5. Press the (Enter) key to confirm your request. If Clr Event
Queue was selected, all event queue entries will then display "No
Event."
Example Screen
Using the PowerFlex
Main Menu:
Diagnostics
Parameter
Device Select
Event Q:
Ping Time Flt
Using the PowerFlex
Dgn: Events
View Event Queue
Clear Event
Clr Event Queue
1 E3
