About Parameter Numbers

Parameter List

Adapter Parameters
Appendix B provides information about the adapter parameters.
Topic
About Parameter Numbers
Parameter List
The parameters in the adapter are numbered consecutively. However,
depending on which configuration tool you use, they may have different
numbers.
Configuration Tool Numbering Scheme
HIM The adapter parameters begin with parameter 01. For example,
DriveExplorer
Parameter 01 - [DPI Port] is parameter 01 as indicated by this manual.
DriveExecutive
Explicit Messaging Refer to
Parameter
No. Name and Description
01 [DPI Port]
Displays the port to which the adapter is connected.
This will usually be port 5.
02 [DPI Data Rate]
Displays the data rate used by the drive. This data rate
is set in the drive and the adapter detects it.
03 [BOOTP]
Configures the adapter to use BOOTP so that you can
set its IP address, subnet mask, and gateway address
with a BOOTP server.
04 [IP Addr Cfg 1]
05 [IP Addr Cfg 2]
06 [IP Addr Cfg 3]
07 [IP Addr Cfg 4]
Sets the bytes in the IP address.
255 . 255 . 255 . 255
[IP Addr Cfg 1]
[IP Addr Cfg 2]
[IP Addr Cfg 3]
[IP Addr Cfg 4]
Important: To set the IP address using these
parameters, Parameter 03 - [BOOTP] must be set to
"0" (Disabled).
Page
B-1
B-1
Chapter 4, Using Modbus/TCP Function Codes
Details
Default:
Minimum:
Maximum:
Type:
Default:
Values:
Type:
Default:
Values:
Type:
Reset Required: Yes
Default:
Default:
Default:
Default:
Minimum:
Maximum:
Type:
Reset Required: Yes
20-COMM-M Modbus/TCP Adapter User Manual
B
Appendix
for details.
5
0
7
Read Only
0 = 125 kbps
0 = 125 kbps
1 = 500 kbps
Read Only
1 = Enabled
0 = Disabled
1 = Enabled
Read/Write
0
0
0
0
0
255
Read/Write
Publication 20COMM-UM014C-EN-P
