2-8 Installing the Adapter

Commissioning the Adapter

20-COMM-M Modbus/TCP Adapter User Manual
Publication 20COMM-UM014C-EN-P
Configuring/Verifying Key Drive Parameters
The PowerFlex 7-Class drive can be separately configured for the control
and Reference functions in various combinations. For example, you could
set the drive to have its control come from a peripheral or terminal block
with the Reference coming from the network. Or you could set the drive to
have its control come from the network with the Reference coming from
another peripheral or terminal block. Or you could set the drive to have
both its control and Reference come from the network.
The following steps in this section assume that the drive will receive the
Logic Command and Reference from the network.
1. Use drive Parameter 090 - [Speed Ref A Sel] to set the drive speed
Reference to "22" (DPI Port 5).
2. If hard-wired discrete digital inputs are not used to control the drive,
verify that unused digital input drive Parameters 361 - [Dig In1 Sel] and
362 - [Dig In2 Sel] are set to "0" (Not Used).
3. Verify that drive Parameter 213 - [Speed Ref Source] is reporting that
the source of the Reference to the drive is "22" (DPI Port 5). This
ensures that any Reference commanded from the network can be
monitored by using drive Parameter 002 - [Commanded Speed]. If a
problem occurs, this verification step provides the diagnostic capability
to determine whether the drive/adapter or the network is the cause.
To commission the adapter, you must set a unique IP address on the
network. (Refer to the Glossary
installing the adapter and applying power, you can set the IP address by
using a BOOTP server or by setting adapter parameters. (See
Address, Subnet Mask, and Gateway Address on page 3-6
By default, the adapter is configured so that you must set the IP address
using a BOOTP server. To set the IP address using adapter parameters, you
must disable the BOOTP feature. See
page 3-6 for details.
Important: New settings for some adapter parameters (for example,
Parameters 04 - [IP Addr Cfg 1] through 07 - [IP Addr Cfg
4]) are recognized only when power is applied to the adapter or
it is reset. After you change parameter settings, cycle power or
reset the adapter.
for details about IP addresses.) After
Disabling the BOOTP Feature on
Setting the IP
for details).
