Accessing the Adapter's
Web Home Page
Viewing the Adapter's Web Pages
This chapter provides instructions on how to monitor the adapter and
connected PowerFlex drive by using the adapter's web interface.
Topic

Accessing the Adapter's Web Home Page

Process Display Pop-up Window
TCP/IP Configuration Web Page
Configure E-mail Notification Web Page
DPI Device Information Pages
Future enhancements may result in adapter web pages that look different
than the examples shown in this chapter.
After configuring the adapter, you can view its web pages. These pages
present information about the adapter, the drive to which it is connected,
and the other DPI devices connected to the drive such as a HIM.
By default the adapter web pages are disabled. To enable the web pages, set
the Web Pages Switch (SW2 in
reset the adapter. Parameter 36 - [Web Enable] can be used to display the
setting (Enabled or Disabled) of this switch.
The adapter can be configured to automatically send e-mail messages to
desired addresses when selected drive faults occur and/or are cleared, and/or
when the adapter takes a communication or idle fault action.
Bit 0 of Parameter 37 - [Web Features] can be used to protect the
configured settings. For more details, see
Web Page on page 6-6.
Page
6-1
6-4
6-5
6-6
6-9
Figure 2.1) to its "Enable Web" position and
Configure E-mail Notification
20-COMM-M Modbus/TCP Adapter User Manual
Publication 20COMM-UM014C-EN-P
