B-4 Adapter Parameters
20-COMM-M Modbus/TCP Adapter User Manual
Publication 20COMM-UM014C-EN-P
Parameter
No. Name and Description
24 [DPI I/O Cfg]
Sets the I/O that is transferred through the adapter.
25 [DPI I/O Act]
Displays the I/O that the adapter is actively
transmitting. The value of this parameter will usually be
equal to the value of Parameter 24 - [DPI I/O Cfg].
26 [Flt Cfg Logic]
Sets the Logic Command data that is sent to the drive
if Parameter 23 - [Comm Flt Action] is set to "4"
(Send Flt Cfg) and communications are disrupted.
The bit definitions will depend on the product to which
the adapter is connected. See
documentation for the drive being used.
27 [Flt Cfg Ref]
Sets the Reference data that is sent to the drive if
Parameter 23 - [Comm Flt Action] is set to "4" (Send
Flt Cfg) and communications are disrupted.
28 [Flt Cfg A1 In]
29 [Flt Cfg A2 In]
30 [Flt Cfg B1 In]
31 [Flt Cfg B2 In]
32 [Flt Cfg C1 In]
33 [Flt Cfg C2 In]
34 [Flt Cfg D1 In]
35 [Flt Cfg D2 In]
Sets the data that is sent to the Datalink in the drive if
Parameter 23 - [Comm Flt Action] is set to "4" (Send
Flt Cfg) and communications are disrupted.
36 [Web Enable]
Displays the setting of the adapter Web Pages Switch
(SW2 in Figure 2.1) when the adapter was last reset.
Details
Default:
Bit Values:
Type:
Reset Required: Yes
Bit
Definition
Default
Bit
Default:
Bit Values:
Type:
Bit
Definition
Default
Bit
Default:
Minimum:
Maximum:
Type:
Reset Required: No
Appendix C or the
Default:
Minimum:
Maximum:
Type:
Reset Required: No
Important: If the drive uses a 16-bit
Reference, the most significant word of
this value must be set to zero (0) or a
fault will occur.
Default:
Default:
Default:
Default:
Default:
Default:
Default:
Default:
Minimum:
Maximum:
Type:
Reset Required: No
Important: If the drive uses 16-bit
Datalinks, the most significant word of
this value must be set to zero (0) or a
fault will occur.
Default:
Values:
Type:
xxx0 0001
0 = I/O disabled
1 = I/O enabled
Read/Write
x x x 0 0 0 0 1
7 6 5 4 3 2 1 0
xxx0 0001
0 = I/O disabled
1 = I/O enabled
Read Only
x x x 0 0 0 0 1
7 6 5 4 3 2 1 0
0000 0000 0000 0000
0000 0000 0000 0000
1111 1111 1111 1111
Read/Write
0
0
4294967295
Read/Write
0
0
0
0
0
0
0
0
0
4294967295
Read/Write
0 = Disabled
0 = Disabled
1 = Enabled
Read Only
