Required Equipment

Safety Precautions

Equipment Shipped with the Adapter
When you unpack the adapter, verify that the package includes:
One adapter
A 2.54 cm (1 in.) and a 15.24 cm (6 in.) Internal Interface cable (only
one cable is needed to connect the adapter to the drive; for which cable
to use, see Figure 2.2 on page
One PowerFlex 7-Class DPI (Drive Peripheral Interface) Network
Communication Adapter Installation Instructions (publication
20COMM-IN004)
User-Supplied Equipment
To install and configure the adapter, you must supply:
A small flathead screwdriver
Ethernet cable – refer to the EtherNet/IP Media Planning and
Installation Manual (publication ENET-IN001)
Configuration tool, such as:
– PowerFlex 7-Class HIM (20-HIM-xx)
– DriveExplorer (version 2.01 or higher)
– DriveExecutive stand-alone software (version 3.01 or higher) or
bundled with the DriveTools SP suite (version 1.01 or higher)
– BOOTP Server (version 2.1 or higher; for network setup only)
Third-party network configuration software tool
A PC connection to the Modbus/TCP network
Please read the following safety precautions carefully.
ATTENTION: Risk of injury or death exists. The PowerFlex
!
drive may contain high voltages that can cause injury or death.
Remove all power from the PowerFlex drive, and then verify
power has been discharged before installing or removing an
adapter.
ATTENTION: Risk of injury or equipment damage exists. Only
!
personnel familiar with drive and power products and the
associated machinery should plan or implement the installation,
start up, configuration, and subsequent maintenance of the
product using an adapter. Failure to comply may result in injury
and/or equipment damage.
ATTENTION: Risk of equipment damage exists. The adapter
!
contains ESD (Electrostatic Discharge) sensitive parts that can be
damaged if you do not follow ESD control procedures. Static
control precautions are required when handling the adapter. If
you are unfamiliar with static control procedures, refer to
Guarding Against Electrostatic Damage (publication
8000-4.5.2).
Getting Started
2-4)
20-COMM-M Modbus/TCP Adapter User Manual
Publication 20COMM-UM014C-EN-P
1-3
