Navigation Menu on Adapter Web Pages
The navigation menu appears on the left side of all adapter web pages,
including its Home page. The navigation menu consists of links and link
folders which can be expanded or minimized. The following table shows all
navigation menu links and link folders:
Table 6.A Navigation Menu Links and Link Folders
Link/Folder Description
Home link Click this link to view the adapter's Home Page
Process Display link Click this link to view the Host's Process Display pop-up window
(Figure
TCP/IP configuration link Click this link to view the adapter's TCP/IP Configuration web page
showing information about the TCP/IP configuration, such as the
adapter's IP address and the number of packets being sent.
Figure 6.3
Configure e-mail notification Click this link to view the adapter's Configure E-mail Notification web
link page
messages. E-mail notification can accommodate specific needs such
as when only selected faults occur
message is shown in
Browse DPI devices folder Click this folder to expand and view the Port folders for all present DPI
devices, including the drive, adapter, and other DPI devices
connected to the drive such as a HIM.
Port x folders Click a respective Port folder to expand and view its device's various links
which take you to related information pages. For Port 0 (PowerFlex 70
Drive) example information pages, see
Figure
Online user manuals link Click this link to view Rockwell Automation's web page with
documentation for drives and other devices.
Software tools Web site link Click this link to view Allen-Bradley's web page with information about
software tools such as DriveExplorer and DriveExecutive.
Launch my DriveExplorer Click this link to launch the DriveExplorer software already installed on
software link your PC.
Launch my DriveExecutive Click this link to launch the DriveExecutive software already installed
software link on your PC.
E-mail technical support link Click this link to view a new e-mail message window to send a
message to Allen-Bradley's Technical Support Team.
Information on Adapter Home Page
The adapter Home Page displays the following information for the adapter
and host:
Information for Description
Adapter Revision
IP Address
Ethernet Address (MAC)
Serial Number
Status
I/O Connection Status
Host "X" Revision
Status
Commanded Direction
Rotation Direction
Process Status
Viewing the Adapter's Web Pages
6.2).
shows an example TCP/IP Configuration web page.
(Figure 6.4) to configure the adapter to send automatic e-mail
(Figure
Figure 6.7.
Figure
6.10.
20-COMM-M Modbus/TCP Adapter User Manual
6-3
(Figure 6.1).
6.5). An example e-mail
6.8, Figure 6.9, and
