Installing Memory Module

Follow the steps below to install the memory module:
Turn the system power off. Press the two keyboard latches to elevate the keyboard
from its normal position. Carefully lift the keyboard assembly out to expose the
mainboard. Locate the memo ry sockets .
1. Position the memory module at a slight angle (45 ) and fit its connectors
into the socket firmly.
2. Press two edges of the memory module (as the arrows indicated) to make
it locked into place.
Reinstall the keyboard assembly.
Note: Make sure you install the memory module in the order of Bake 0, Bank1.
Chapter 2—Operation 2-8
Figure 2-8
