Using Cd-Rom - EUROCOM DeskNote 3100C Manual

Using CD-ROM

The DeskNote is equipped with a removable CD-ROM drive module. It is usually
designated as drive D by default and may be used as a boot device if properly set
(please refer to Chapter 3, BIOS Utilities). You may replace CD-ROM drive module
with following options, DVD-ROM drive (of 12.7mm), CD-RW drive or the third
battery pack.
To insert a CD, press the Eject Button and place the CD on the Disc Tray label-
side facing up. Push the CD tray in and you are ready to start. The Busy Indicator
will light up while data is being accessed or while an audio CD is playing. When
power to the system is unexpectedly interrupted, insert an instrument such as a
straightened paper clip into the Emergency Eject Hole to manually eject the tray.
Figure 2-14
Chapter 2—Operation 2-15
Disk Tray
Emergency Eject
Hole
Busy Indicator
Eject Button
