Upgrading Processor Module
Replacing Processor Module
1.
Remove all power sources (AC power and battery).
2.
Turn the DeskNote over.
3.
Remove the CPU cover.
4.
Remove the screws that fasten the heat sink mounted on the Processor Module.
5.
Carefully use the CPU removing tool to detach the Processor Module from the
mainboard.
Note:
Wait for the CPU to cool down before replace it.
Contract your dealer for the CPU tool to replace the CPU.
Chapter 2—Operation 2-2
Figure 2-1
CPU Cover
Heat Sink
CPU Module
