Using Hard Disk Drive
The DeskNote is equipped with a 2.5" IDE hard disk drive mounted in a removable
case. Therefore, the hard disk drive can also be easily removed and replaced with
another hard disk drive with a height of 17mm by using different case. The hard disk
drive supports Programmed I/O (PIO) mode 4, Master mode and Ultra ATA (Ultra
DMA-33) mode which can provide a high performance data transfer rate at speeds
up to 33 MB/second.
Removing the Hard Disk Drive Module
Turn off the power. Turn the DeskNote over.
1.
Push the latch in the direction as indicated.
2.
Pull the hard disk cover up.
3.
Draw the hard disk drive module out of the bay.
Chapter 2—Operation 2-10
Figure 2-10
