Installing the Memory Module

Follow the steps below to install the memory module:
1. Turn the system power off.
2. Press the two keyboard latches to elevate the keyboard from its normal
position.
3. Carefully lift the keyboard assembly out to expose the mainboard.
Locate the memory sockets (Figure 2-8).
4. Position the memory module at a slight angle (45
connectors into the socket firmly (Step 1 of Figure 2-9).
5. Press two edges of the memory module (Step 2 of Figure 2 -8) to
make it locked into place.
6. Reinstall the keyboard assembly.
Note:
It is recommended to install the memory module in the order of Bank 0,
Bank 1 (see Figure 2-10). Please refer to the table of DRAM
combinations or consult your dealer for a proper installation.
2-10 User's Manual
) and fit its
Figure 2-9
