Setting DIP Switch

Flash ROM BIOS update

In order to keep up with the latest system BIOS, your DeskNote may be upgraded.
Consult your dealer for further information. The DIP-Switch needs to be set in the
On position when updating the existing system BIOS. The DIP-Switches should be
reset to the Off position after BIOS updating is complete.
DIP Switch (SW1)
SW1-1
Off
On

CPU Core Frequency Settings

The correct configuration for CPU core frequency is listed as follows:
CPU Frequency
233MHZ
266MHZ
300MHZ
333MHZ
366MHZ
CPU Frequency
1.5V (Socket 370)
1.6V (BGA1)
Chapter 2—Operation 2-4
SW1-2
Off
On
BGA1 Processor
SW1-4 SW1-5
ON
ON
ON
ON
ON
Celeron & BGA1 Processor VTT Select
Flash ROM BIOS
SW1-6
OFF OFF
ON
OFF
ON OFF
OFF OFF
S3-1
ON
OFF
Purpose
Existing BIOS
Updating BIOS
SW1-7
ON
ON OFF
ON OFF
OFF
OFF
S3-2
ON
OFF
