Disassembly

Removing the CD Device

1. Turn off the computer, remove the battery
Figure 6
2. Remove screw
CD Device Removal
3. Use a screwdriver to carefully push the CD device assembly
4. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
a. Remove the screws.
screw holes should line up.
b. Carefully lift the cover off
5. Replace the CD device removal cover and the screw.
the computer.
c. Push the CD device out
6. Restart the computer to allow it to automatically detect the new device.
off the computer at point
2.
d. Remove the CD device. a.
c.
2. CD Device Remov-
al Cover
3. CD Device
• 1 Screw
2 - 12 Removing the CD Device
