Disassembly

Removing the LCD Panel

1. Turn off the computer, remove the battery
Figure 18
(page 2 -
LCD Panel Removal
2. Remove screws
3. Gently lift the LCD panel
a. Remove screws from the
side of the LCD panel.
a.
b. Lift the LCD panel off the
LCD assembly.
1
7. LCD Panel
• 4 Screws
2

Removing the PC Camera Module

Figure 19
PC Camera Removal
1. Turn off the computer, remove the battery
2. Disconnect cable
a. Disconnect the cable.
3. Lift the PC camera module
b. Lift the PC Camera off
the LCD assembly.
2. PC Camera
2 - 24 Removing the LCD Panel
14), bottom case (page 2 - 17), mainboard
- from the side of the LCD panel
1 4
off the LCD assembly
7
from the PC camera module
1
(Figure 19b) off the LCD assembly.
2
a.
1
(page 2 - 7), hard disk (page 2 -
(page 2 - 20), and inverter
(Figure 18a).
(Figure 18b).
b.
3
4
(page 2 - 7), and inverter (page 2 -
(Figure 19a).
b.
8), CD Device (page 2 - 12), CPU
(page 2 - 22).
7
22).
2
