Disassembly

Removing the Hard Disk Drive and Wireless LAN

The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives
Figure 2
with a height of 9.5mm (h). Follow your operating system's installation instructions, and install all necessary drivers and
HDD Assembly &
utilities (as outlined in Chapter 4 of the User's Manual) when setting up a new hard disk.
Wireless LAN
Removal
Hard Disk Upgrade Process
a. Remove the 2 screws.
1. Turn off the computer, remove the battery
b. Remove the cover.
2. Remove screws
c. Disconnect the cables
from the Wireless LAN
module.
HDD System Warning
New HDD's are blank. Be-
fore you begin make sure:
You have backed up any
data you want to keep from
your old HDD.
You have all the CD-ROMs
and FDDs required to in-
stall your operating system
and programs.
If you have access to the
internet, download the lat-
est application and hard-
ware driver updates for the
3. Hard Disk Cover operating system you plan
to install. Copy these to a
• 2 Screws
removable medium.
2 - 8 Removing the Hard Disk Drive and Wireless LAN
(page 2 -
&
(Figure 2a), and remove the hard disk cover
1 2
a.
1
2
7) and turn it over.
.
3
b.
3
