Disassembly

Removing the CD Device

The easy changeable CD device may be upgraded or changed.
1. Turn off the computer, and remove the battery (
2. Remove screws
3. Carefully lift up the memory socket cover
nect it).
a.
Figure 5
Memory Socket
Cover Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
7. Socket Cover
• 6 Screws
2 - 12 Removing the CD Device
- (Figure 5a) from the memory socket cover
1 6
7
1
6
2 3
4 5
page 2 - 8 ).
.
(a fan cable is still attached to the mainboard and you can discon-
8
b.
7
8
