6. Turn the release latch towards the unlock symbol
1
7. Carefully (it may be hot) lift the CPU
8. When re-inserting the CPU, pay careful attention to the pin alignment, it will fit only one way (don't force it!).
a.
b.
, to unlock the CPU
up out of the socket (Figure
2
1
Unlocked
2
(Figure 9a).
9b).
Locked
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
Disassembly
Figure 9
Processor Removal
(cont'd)
a. Turn the release latch to
unlock the CPU.
b. Lift the CPU out of the
socket.
2. CPU
Removing the Processor 2 - 15
