Removing the Speakers

1. Turn off the computer, remove the battery
(page 2 - 14), bottom case (page 2 -
2. Remove the screws - (Figure
1 4
3. Separate the speakers (Figure
5
a.
1
b.
(page 2 - 7), hard disk
17), mainboard (page 2 -
17a) from the speakers.
17b) from the LCD front panel assembly.
2
5
(page 2 - 8), CD Device (page 2 -
20), and inverter (page 2 - 22).
4
3
5
Disassembly
12), CPU Figure 17
Speakers Removal
a. Remove the screws.
b. Separate the speakers
from the LCD front panel
assembly.
5. Speakers
• 4 Screws
Removing the Speakers 2 - 23
