Keyboard

• A4 Size Win 95 Keyboard (3mm travelling)
• Built-In TouchPad with Scrolling Function

Interface

• Two USB 2.0 Ports
• One Mini- IEEE 1394 Port
• One External CRT Monitor Port
• One Headphone-Out Jack
• One Microphone-In Jack
• One S/P DIF Output Jack
• One TV-Out Jack
• One RJ-11 Jack for Plug & Play Fax/Modem
• One RJ-45 Jack for 10M/ 100M Fast Ethernet
• One DC-in jack

Communication

• 56K Plug & Play Fax/Modem V.90/92 Compliant
• 10M/100M Fast Ethernet (IEEE 802.3 and 802.3u
Standard Compliant)
• CMOS Camera with USB Interface
• INTEL PRO/Wireless LAN 2100 module with Mini-PCI
interface
• Bluetooth 1.1 with MDC Interface (optional)

Power Management

• Supports ACPI 2.0
• Soft Off by system Power Button
• Supports Suspend to disk
• Supports Suspend to RAM
• Supports Battery Low Suspend
• Supports Resume From Alarm Time
• Supports Resume From Modem Ring
• Supports Wake on LAN

Power

• Full Range AC Adapter
AC-Input 100~240V, 47~63Hz
DC Output 20V, 3.25A (65W)
• 1st Smart Lithium-Ion (6 cells)
• 2nd Smart Lithium-Ion (12 cells) - optional

Indicators

• LED Indicators (Power/Suspend, Battery, HDD/CD-ROM,
Num Lock, Caps Lock, Scroll Lock, E-Mail, 802.11b &
Bluetooth)

Buttons

• E-Mail
• Internet Browser
• Power
• On/Off Switch for optional 802.11b & Bluetooth
Introduction
System Specifications 1 - 3
