External Locator - Front & Left Side Views
Figure 3
Front View
1. LCD Latches
2. Hot-Key Buttons
Figure 4
Left Side View
1. Vent
2. External Monitor
(CRT) Port
3. S-Video-Out Port
4. RJ-11 Phone Jack
5. RJ-45 LAN Jack
6. 2 * USB 2.0 Ports
7. IEEE 1394 Port
8. PC Card Slot
Eject Button
9. PC Card Slot
