- Page 1 ® Intel Atom™ Processor E660 with ® Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002...
- Page 2 MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. A "Mission Critical Application" is any application in which failure of the Intel Product could result, directly or indirectly, in personal injury or death. SHOULD YOU PURCHASE OR USE INTEL'S PRODUCTS FOR ANY SUCH MISSION CRITICAL APPLICATION, YOU SHALL INDEMNIFY AND HOLD INTEL AND...
-
Page 3: Table Of Contents
Power Management ....................31 Power Measurement Support ................31 Reference Board Summary ..................35 ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit Features .................. 35 Connectors ....................... 36 Configuration Settings ..................38 4.3.1 Configuration Jumpers/Switches............... 38 4.3.2... - Page 4 Where to Download.................53 5.3.3 BIOS/EFI Firmware Update Tool..............53 5.3.4 EFI Firmware/BIOS Status Code ...............53 ® 5.3.5 Links to Vendors Providing a BIOS Solution for the Intel Atom™ Processor E660..................54 WinCE BSP Vendors ...................54 ® Intel Embedded and Media Graphic Driver............54 Virtual Machine Monitor Software (VMM Software)..........54...
- Page 5 Carrier Board LEDs....................48 JTAG Chain Jumper Options on the COM Express* Module ..........49 Software Availability Overview ................... 51 ® ® Platform Drivers for the Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit ............... 52 ®...
-
Page 6: Revision History
OS. Updated description of included January 2012 panel display. First release of development kit. October 2010 § § ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 7: Introduction
Note: Read this document in its entirety prior to applying power to the reference platform. Intel recommends having the schematic files and development kit boards present while reading this document. The references in this document correlate to reference ®... -
Page 8: Terminology
Keyboard Controller Local Area Network Light Emitting Diode Low Pin Count LVDS Low Voltage Differential Signaling Multi Media Card ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... - Page 9 Transmitter or Transmit (in reference to PCI Express* differential signal pairs) Transmit Data UART Universal Asynchronous Receiver Transmitter Universal Serial Bus Voltage Regulator ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002...
-
Page 10: Technical Support
Platform Controller Hub Shell Bay EG20T ® Note: Shell Bay is available as a customer reference board for developing applications with the Intel Platform Controller Hub EG20T. Technical Support Support Services for your hardware and software are provided through the secure ®... -
Page 11: Reference Documents
Serial Digital Video Out (SDVO) Port Note External Design Specification (EDS) Notes: Sightings Reports will only be available when there are sightings to report. Contact your Intel Field Representative for the latest version of this document. ® ® Intel Atom™ Processor E660 with Intel... - Page 12 BOSCH CAN Specification Version 2.0 http://www.semiconductors.bosch.de/pdf/can2spec.pdf Notes: Sightings Reports will only be available when there are sightings to report. Contact your Intel Field Representative for the latest version of this document. § § ® ® Intel Atom™ Processor E660 with Intel...
-
Page 13: Getting Started
This manual assumes a familiarity with basic concepts involved with installing and configuring hardware for a PC. ® ® Figure 1. Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit ® ® Intel Atom™ Processor E660 with Intel... -
Page 14: Overview
Note: PCIe* x4 slots only have x1 connection. Overview ® The development kit contains the Intel Atom™ Processor E660 (populated on the COM Express* module), other system board components and peripheral connectors and a ® carrier board with the Intel Platform Controller Hub EG20T. -
Page 15: Major Features
22 X 22 mm FCBGA package with 0.8 mm diagonal ball pitch and 676 pins. ® ® Intel Mobile Voltage Positioning 6 (Intel Single phase voltage regulators (U5C1, U5B2) on the CPU Voltage Regulator MVP 6) COM Express module. Little Bay: 4.92 x 3.74 inch (125 x 95 mm) Board Size Doubled-sided placement. - Page 16 Power management S3 – Suspend to RAM ACPI Compliant (ACPI) (S4 – Suspend to Disk) S5 – Soft Off ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002...
-
Page 17: Processor Support
The I/O voltage is 1.05 V. COM Express* Module Support ® The carrier board supports the COM Express* module with the Intel Atom™ Processor E660. A heatsink is required for the 1.0 GHz or above processor SKUs during room temperature ambient operation. -
Page 18: Intel ® Platform Controller Hub Eg20T
Super I/O (PS2), 1 port, Low Pin Count Interface CPLD (POST Indication), Pin Header ® ® AC’97/ Intel 1 port, Audio Codec ’97, Intel High Definition Audio Audio Codec IC Audio Interface Option EEPROM for PCI Bridge 1ch, Inter-Integrated Circuit... -
Page 19: Display
• LVDS – location is X4 • SDVO – location is X9 ® ® Note: The Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit supports single channel LVDS only. Table 7 lists the displays that have been tested with the kit. -
Page 20: Sata Connectors
There is one peripheral power connector (X48) provided for the purpose of powering external devices such as a SATA drive. Figure 4 describes the carrier board SATA interface connection. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 21: Usb Connectors
(ROHM BD2052AFJ* Continuous current load: 0.50A by a port) in ® the VBUS output for the purpose of validating the Intel PCH EG20T. Therefore, additional power supply may be necessary depending on the USB device to connect. -
Page 22: Gigabit Ethernet Connector
2.5.9 Gigabit Ethernet Connector ® The carrier board provides one Gigabit Ethernet interface from the Intel PCH EG20T via a Realtek RTL8211CL* Gigabit Ethernet PHY transceiver. The Gigabit Ethernet port (X26) is routed to the rear I/O panel's stacked receptacle. -
Page 23: Uart
— Supports 300k and 4Mbps Baud Rate but X19 port supports up to 1Mbps following RS-232C transceiver’s specification. — Programmable Baud Rate Generator ® — Enables auto hardware flow control of the Intel PCH EG20T — UART port 1-3: — Assigned rear I/O panel’s D-Sub 9pin stacked connectors (X17; UART2, X18;... -
Page 24: Uart Block Diagram In The Carrier Board
A fault in the setting could damage the platform, the interconnecting cable, or the attached external device. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 25: I 2 C
2.5.12 ® The carrier board provides one I C* port from the Intel PCH EG20T that conforms to the typical I C* bus specification. It operates as a master or slave device and supports ®... -
Page 26: Spi
(standard format and extended format). The bit rate can ® be programmed to a maximum of 1Mbit/s based on the technology used. The Intel PCH EG20T CAN bus is connected to the 1x4 2.54mm pin header (X39) via CAN transceiver NXP TJA1040T*. -
Page 27: Lpc Bus
® The Intel HD Audio is enabled through the Realtek ALC888* CODEC. Six port Intel HD Audio jack (X27) is provided on the rear I/O panel. No SPDIF receptacle is provided on the carrier board. For the front panel, only a 2x5 header (X36) is provided. -
Page 28: Clock Circuit Diagram In The Carrier Board
*1: One of the UART port is up to 4Mbps baud rate clock, the other ports are up to 1Mbps. *2: LPC CLK Buffer is no PLL locked type. (e.g. ICS553 ) ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 29: Real Time Clock
(up to OS functionality). Ports 80-83 are provided as a troubleshooting tool to monitor POST output during EFI execution. ® ITP requires that the CMC be loaded to configure the Intel Atom™ Processor E660 before register accesses can be made. The CMC code resides in the SPI flash on the COM Express* module. -
Page 30: Power Supply Solution
The form factor of the carrier board follows Micro ATX 9.6 x 8 inch (243.84mm x 203.2mm) specification. The back panel jacks may not conform to ATX specifications. § § ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 31: Power Management
1206 2512 Note: Intel recommends that larger (~10 m ) resistors be stuffed for greater accuracy. Power on a particular subsystem is calculated using the following formula: Equation 1. P = V R = value of the sense resistor (typically 0.01 V = the voltage difference measured across the sense resistor. -
Page 32: Digital Multi-Meter Comparison
3.3V D33VS D33_VS_SD_SLOT1 R395 Resistor-1 Hiside SW Pow for Hiside SW for D50V_D50VS 5.0V D50V_D50VS_USB_Port2, R151 Resistor-1 D50V_D50VS_USB_Port2,3 _USB2_5 ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... - Page 33 CLK Buf, SIO,32.768kHz OSC for 3.3V D33VA D33V_D33VS R536 Resistor-1 SIO,RS232C Drv, RS485 Drv PCH(PLA), GbE-PHY 2.5V D33VA D25VA R535 Resistor-1 ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002...
- Page 34 PCH(PLC), Reset IC for PCH 1.2V D12VA D12VS R539 Resistor-1 IOVDDC PCIe* to PCI Bridge 1.0V D10V D10VS R540 Resistor-1 § § ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002...
-
Page 35: Reference Board Summary
Reference Board Summary Reference Board Summary ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit Features Figure 10. COM Express* Module Components (Top View) Thermal DDR2 Sensor ® ® Intel Intel Atom™ Atom™ Atom™ DDR2... -
Page 36: Connectors
A fault in the load presented by the external devices could damage the computer, the interconnecting cable, or the attached external device. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 37: Carrier Board Connectors
X 23 X1 9 X1 4 X 22 X 27 X 26 X 21 X1 5 X 16 X 20 ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 38: Configuration Settings
Always turn off the power and unplug the power cord from the computer before changing jumper settings. Otherwise, damage to the board could occur. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 39: Com Express* Module Configuration Jumpers/Switches
The development kit is shipped with the jumpers and switches shunted in the default locations. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 40: Carrier Board Configuration Jumpers/Switches
1 to pin 2), 2-3 (to short pin 2 to pin 3), etc. When no jumper cap is to be placed on the jumper, it is designated as OPEN or OUT. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 41: Configuration Jumper Settings On Carrier Board
1 to pin 2), 2–3 (to short pin 2 to pin 3), etc. When no jumper cap is to be placed on the jumper, it is designated as OPEN. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... - Page 42 1 to pin 2), 2–3 (to short pin 2 to pin 3), etc. When no jumper cap is to be placed on the jumper, it is designated as OPEN. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002...
-
Page 43: Bsel Jumper Settings
2-3 short: 12V supply at X53 Power SW signal to COMe module select 1-2 short: SW5 signal connect to COMe module directly Power SW to ® 2-3 short: SW5 and Intel PCH EG20T wake_out_n signal 2-3 short 2-3 short COMe Select... -
Page 44: Manual Vid Support For Cpu
“VID override” circuit is to enable debugging and testing. See Table 16 for the VID code table. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 45: Vid Vs
‘1’ on the corresponding VID signal. Closing the jumper position will result in logic ‘0’ on the corresponding VID signal. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 46: Power On And Reset Push Buttons
LEDs and Table 17 describes the functions of the LEDs and their reference designators. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 47: Carrier Board Leds
Reference Board Summary Figure 15. Carrier Board LEDs D16 D15 D14 D9 D10 D1 D2 D3 D11 D12 ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 48: Pci Express* Routing
PCI Express* Routing 4.6.1 PCI Express* x1 Port0 ® This is the first PCIe* port from the COM Express* module. It connects to the Intel PCH EG20T. 4.6.2 PCI Express* x1 Port1 This is the second PCIe* port from the COM Express* module. The PCI Express* port 1 link connects to a PCIe*-PCI bridge (Pericom PI7C9X111SL*) which provides one PCI slot (X12). -
Page 49: Pci Express* X1 Port3
Figure 16 shows the JTAG chain on the COM Express* Module. Figure 16. JTAG Chain on the COM Express* Module ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... - Page 50 Reference Board Summary ® The carrier board has two JTAG headers. One is used for the Intel PCH EG20T internal boundary scan testing and signal monitoring in validation. The other is used the CPLD’s firmware programming. These JTAG interfaces are not chained and each header is different.
-
Page 51: Software
Enabled ByoSoft ® Intel Intel (http://edc.intel.com/Platforms/Atom- Embedded All supported OS as above E6xx/#software) Graphic Driver VMM Software Tenasys Tenasys ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 52: Platform Drivers For The Development Kit
• Supports Intel Virtualization Technology for IA-32 and Intel Architecture (Intel ® VT-x ) in hardware and can be enabled through the Intel VT option in the BIOS setup menu • Supports Digital Thermal Sensor • Supports Thermal Management (TM) and Thermal Management 2 (TM2) and can be enabled/disabled in the BIOS setup option menu •... -
Page 53: Where To Download
Specification Updates or Sightings Reports (if available) before implementing any of the above features. 5.3.2 Where to Download The EFI firmware is available at http://edc.intel.com/Platforms/Atom-E6xx/#software. 5.3.3 BIOS/EFI Firmware Update Tool The development kit EFI firmware can be upgraded/reflashed using either of two methods: •... -
Page 54: Links To Vendors Providing A Bios Solution For The Intel
• Phoenix Technologies (http://www.phoenix.com) • Insyde Software (http://www.insydesw.com) • Byosoft Co., Ltd (http://byosoft.com.cn/en/index.asp) WinCE BSP Vendors ® Below are the links to WinCE OS vendors who support the Intel Atom™ Processor ® E660 and Intel PCH EG20T for Embedded platform: Adeneo - http://www.adeneo-... -
Page 55: Cpld Firmware Update
Software Included in the Development Kit 1. The hard disk that is included in the development kit is preloaded with: — Timesys Fedora* Remix OS which includes all the Intel PCH Drivers. — For the latest Intel PCH drivers, you may obtain from http://sourceforge.net/projects/generalembedded/files/... -
Page 56: Operating System Installation
This is due to USB issue in the Intel PCH EG20T A0 and A1 silicon. Refer to the Intel® Platform Controller Hub EG20T – Sightings Report for more information. Some USB floppy drivers are not supported during F6 installation. See details at http://support.microsoft.com/kb/916196. -
Page 57: Selecting The Scsi Adapter
Software ® installation. This will install the Intel PCH EG20T SATA AHCI controller driver (Figure 18). Figure 18. Selecting the SCSI Adapter ® Note: Slipstreaming the Intel PCH EG20T SATA AHCI controller driver onto the Windows XP SP3 installer will not work. -
Page 58: Usb Host Controller #1 Port Connection
Figure 19. USB Host Controller #1 Port Connection 8. Finish the Windows XP installation according to your needs. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 59: Meego
To use the embedded graphics drivers, refer to the EMGD site: http://www.intel.com/p/en_US/embedded/hwsw/software/emgd ® Follow the download and installation instructions provided in the Intel Embedded Media and Graphics Driver v1.10 for Windows* XP, Windows* Embedded Compact 7 and Linux* User Guide. -
Page 60: Quick Start
• Associated cables Note: PCIe* and ADD2-N (VGA output provided) graphics card “Quick Start” is not included in this document. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 61: Display Assembly (Lvds Panel)
Quick Start Display Assembly (LVDS Panel) Figure 20. AUO 8.4 inch Panel ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 62: User Manual January
Quick Start Figure 21. LVDS Cable Connected to the Carrier Board ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 63: Lvds Connector And Cable
2. Attach the additional +12V built onto the LVDS cable for LED backlight to onboard 12V supply at X53. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 64: Heat Sink Installation
If you are reinstalling the heat sink after removing it, you may also need thermal interface material (TIM). 6.3.1 COM Express* Module and Carrier Board Figure 23. COM Express* Module and Carrier Board ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 65: Heat Sink Installation
4. Attach the gap pad and sponge to the center of the heat sink as shown in Figure Figure 25. Back Side of the Heat Sink ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit January 2012 User Manual Document Number: 324213-002... -
Page 66: Power On
3. Check time, date and configuration settings. For most users the default setting should be sufficient for the initial bring-up. 4. Press F10 to save and quit the BIOS setup. ® ® Intel Atom™ Processor E660 with Intel Platform Controller Hub EG20T Development Kit User Manual January 2012 Document Number: 324213-002... -
Page 67: Power Down
2. If the system is hung, it is possible to asynchronously shut the system down by holding the power button (SW5) down continuously for at least 3 seconds. Note: Intel does not recommend powering down the board by shutting off power at the ATX power supply. § §...
