Euphonix System 5 Installation Guide

MADI Out (BNC): Outputs the digital audio signal.

•

1–24:

•

25–26: Aux analog inputs

•

27–28: Aux digital inputs

NOTE: 28 channels are always transmitted; dual channels are not used.

Trim Switches : Four detented trim rotary switches, accessed from the front panel, adjust the

analog input level of channels 1–8, 9–16, 17–24, and auxiliary analog in 2 dB steps between

+12 and +26 dBU.

Analog inputs

System 5 Components
