Euphonix System 5 Installation Guide
1
AES/SYNC IN (female XLR or BNC), WORD IN (BNC): Connect this port to
1
a digital sync reference (local unit only). Selection for XLR or BNC input is done
using two internal jumpers shown in Figure 3-39 Internal Sync Input Jumper.
The unit is shipped from the factory with the jumpers set for the XLR input.
AES/SYNC OUT (male XLR or BNC), WORD OUT (BNC): Connect one of
2
these ports to the digital sync reference input of any device receiving MADI at
the remote unit. Only one output connection (XLR or BNC) should be used at a
time.
RETIMED AES/SYNC OUT (male XLR), RETIMED WORD OUT (BNC):
3
Connect one of these ports to the digital sync reference input of any device send-
ing MADI from the remote unit back to the local unit.
2
Figure 3-42 Rear Panel Sync Connectors
BNC
Figure 3-43 Internal Sync Input Jumper
84
System 5 Components
3
XLR
.
