External Locator - Top View with LCD Panel Open

1
2
3
5
6
7
7
9
4
8
External Locator - Top View with LCD Panel Open 1 - 5
Introduction
Figure 1
Top View
1. Optional Built-In PC
Camera
2. LCD
3. Ap-Key Buttons
4. Power Button
5. Keyboard
6. TouchPad and
Buttons
7. Audio "DJ" Controls
8. Built-In Microphone
9.
Audio "DJ" LED
Display Panel
(Including LED
Indicators)
Audio "DJ" &
Power Button
Make sure that the Au-
dio "DJ" player is off
before pressing the
power button to turn
the computer on.
